PLC Programming Applications

$400.00

Out of stock

SKU

PLCE/57

The fifth in our PLC programming course collection is designed for people who want to configure PLC hardware and develop and write PLC programs using binary and integer word instructions such as analogue, from more detailed project specifications.

For information on course content, learning activities, and assessment click here

Details

PLC Application

This course is designed for those who have completed our PLC Programming Taster, PLC Programming Introduction, PLC Programming Software, and PLC Programming Essentials courses, or have an intermediate understanding of PLCs and programs and want to create more detailed projects using word PLC instructions to develop programs for analogue systems. Additionally, work with number systems to solve problems. PLC instructions used include bit, word, double word, and analogue. Each project uses a process description to develop a PLC ladder program solution. This is the same method used in industry to write PLC programs to a customer specification. Assessments are based upon the relevant performance and skills requirements described in the UEE Electrotechnology training package. Completion of this course will prepare you for the next course in the series PLC Programming Advanced.

Content

5 PLC Training Projects
5 Training Videos
Online Learning and Study Resources
Online Knowledge and Skills Quizzes
Scheduled Online Q&A Sessions
Certificate of Completion
Hrs to Complete - 50

Outcomes

Apply WHS/OHS practices
Download and install Rockwell CCW PLC software
Develop PLC programs from a detailed specification
Edit and modify PLC programs
Test and debug PLC programs
Use bit, word, and math instructions in programs
Analogue considerations for PLC hardware and programs
Use PLC instructions
- Word, Double Word, Real, Math

Assessment

This course covers some of the outcomes described in the following national UEE Electrotechnology training package competencies:

UEECD0007 - Apply work health and safety regulations, codes and practices in the workplace
UEECD0051 - Use drawings, diagrams, schedules, standards, codes and specifications
UEECS0033 - Use engineering applications software on personal computers
UEEIC0013 - Develop, enter and verify discrete control programs for programmable controllers
UEEIC0015 - Develop, enter and verify word and analogue control programs for programmable logic controllers

and skill set:

UEESS00135 - Instrumentation - Programmable Control Systems Skill Set

More Information

More Information
Who Should Attend	Suitable for experienced personnel working in automation or electrical roles, including electricians, electrical technicians, engineers, and maintenance staff who want to strengthen their skills in PLC operation, troubleshooting, and control applications.
Prerequisites	To complete this course, you should have finished PLC Programming Essential, or have suitable PLC programming experience, and be familiar with common Microsoft Windows tasks such as file management, navigation, s
Hours to Complete	The course requires about 50 hours to complete. Actual time may vary depending on learning pace, computer skills, and how much time is spent reviewing optional resources or practising the included activities.
Software Download	Participants receive links to download and install Rockwell Software Connected Components Workbench (CCW) Standard Edition (Free). CCW must be installed to access lessons, simulations, and course activities. Refer to Terms and Conditions for details.
Computer Hardware	A computer meeting the minimum specifications is required. A higher‑performance system will improve responsiveness when running CCW, simulations, and other course software used throughout the training.
Computer Requirements	Minimum specifications: Intel Core i5 2.4 GHz or equivalent, 8 GB RAM, 20 GB free disk space with at least 2 GB for the installer, and a Windows‑compatible pointing device such as a mouse or trackpad for accurate navigation.
Operating System	CCW supports 64‑bit Windows 10 and Windows 11 Professional or Enterprise. Microsoft .NET Framework 3.5 SP1 must be manually enabled or installed to ensure correct operation of CCW and related course software.
